Optical Transceiver Hot-Pluggable and 200G QSFP56 to 2x 100G QSFP56 Active Optical Cable with Breakout PAM4 Modulation

Product Categories
Hong Kong Starsurge Group Co., Limited
Contact Now

Optical Transceiver Hot-Pluggable and 200G QSFP56 to 2x 100G QSFP56 Active Optical Cable with Breakout PAM4 Modulation

Model Number : CC-AOC-Q2Q1-xxC

Place of Origin : China

Brand Name : Starsurge

Price : Negotiable

Certification : RoHS CE FCC UL

MOQ : 1 pc

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 10000pcs/month

Delivery Time : 2-7days

Packaging Details : carton

Type : Optical Transceiver

Use : Data Center, Cloud Computing, 200G InfiniBand HDR

Warranty Time : 1 year

Network : Data Center Network, Cloud Network, InfiniBand Net

Port : QSFP56 200G Port x 1, QSFP56 100G Port x 2

Connector Type : QSFP56

Frequency Range : PAM4 Modulation, up to 53.125Gbps per channel

Product name : CC-AOC-Q2Q1-xxC

Operating Temperature : 0℃ to 70℃

Standards Compliance : IEEE 802.3cd, InfiniBand 4xHDR, SFF 8679, CMIS4.0 or SFF8636

Product Type : Active Optical Cable (AOC) with QSFP56 200G

Data Rate : Up to 53.125Gbps per channel (PAM4 modulation)

Modulation Technology : PAM4 (Pulse Amplitude Modulation)

Contact Now

Optical Transceiver Hot-Pluggable and 200G QSFP56 to 2x 100G QSFP56 Active Optical Cable with Breakout PAM4 Modulation
Optical Transceiver Hot-Pluggable and 200G QSFP56 to 2x 100G QSFP56 Active Optical Cable with Breakout PAM4 Modulation
200G QSFP56 SR4 to 2xQSFP56 SR2 Active Optical Cable CC-AOC-Q2Q1-xxC
Applications
 Datacenters and Cloud
 Networks
 200G InfiniBand HDR systems
Features
 Active optical cable with breakout from QSFP56 200G to two QSFP56 100G
 Up to 53.125Gbps data rate per channel PAM4 modulation
 Integrated 850nm VCSEL array and PD array
 DDM function implemented
 Hot-pluggable
 Low power dissipation
Commercial operating case temperature range: 0℃ to 70 ℃
 Compliant with ROHS2.0
Optical Transceiver Hot-Pluggable and 200G QSFP56 to 2x 100G QSFP56 Active Optical Cable with Breakout PAM4 Modulation
Optical Transceiver Hot-Pluggable and 200G QSFP56 to 2x 100G QSFP56 Active Optical Cable with Breakout PAM4 Modulation
Optical Transceiver Hot-Pluggable and 200G QSFP56 to 2x 100G QSFP56 Active Optical Cable with Breakout PAM4 Modulation
Optical Transceiver Hot-Pluggable and 200G QSFP56 to 2x 100G QSFP56 Active Optical Cable with Breakout PAM4 Modulation
Optical Transceiver Hot-Pluggable and 200G QSFP56 to 2x 100G QSFP56 Active Optical Cable with Breakout PAM4 Modulation
Optical Transceiver Hot-Pluggable and 200G QSFP56 to 2x 100G QSFP56 Active Optical Cable with Breakout PAM4 Modulation
Optical Transceiver Hot-Pluggable and 200G QSFP56 to 2x 100G QSFP56 Active Optical Cable with Breakout PAM4 Modulation
Optical Transceiver Hot-Pluggable and 200G QSFP56 to 2x 100G QSFP56 Active Optical Cable with Breakout PAM4 Modulation
Optical Transceiver Hot-Pluggable and 200G QSFP56 to 2x 100G QSFP56 Active Optical Cable with Breakout PAM4 Modulation
Optical Transceiver Hot-Pluggable and 200G QSFP56 to 2x 100G QSFP56 Active Optical Cable with Breakout PAM4 Modulation
